linux下用傲腾作为缓存加速机械硬盘读写

[global]
ioengine=libaio
direct=1
group_reporting
runtime=60
time_based=1
size=512M
directory=/mnt/hdd/seagate/
filename=fio_mark_test.file

# group 0. SEQ1M Q8T1 顺序读
[SEQ1M-Q8T1]
rw=read
bs=1M
iodepth=8
numjobs=1
stonewall
# group 1. SEQ1M Q8T1 顺序写
[SEQ1M-Q8T1-Write]
rw=write
bs=1M
iodepth=8
numjobs=1
stonewall

# group 2. RAND4K Q32T16 随机读
[RND4K-Q32T16]
rw=randread
bs=4k
iodepth=32
numjobs=16
stonewall

# group 3. RAND4K Q32T16 随机写
[RND4K-Q32T16-Write]
rw=randwrite
bs=4k
iodepth=32
numjobs=16
stonewall

# group 4. RAND4K Q1T1 随机读
[RND4K-Q1T1]
rw=randread
bs=4k
iodepth=1
numjobs=1
stonewall

# group 5. RAND4K Q1T1 随机写
[RND4K-Q1T1-Write]
rw=randwrite
bs=4k
iodepth=1
stonewall

[global]
ioengine=libaio
direct=1
group_reporting
runtime=60
time_based=1
size=512M
directory= /mnt/hdd/seagate/ # 自行修改路径, 对应磁盘的任意位置都可以;
filename=fio_mark_test.file

# group 0. SEQ1M Q8T1 顺序读
[SEQ1M-Q8T1]
rw=read
bs=1M
iodepth=8
numjobs=1
stonewall

# group 1. SEQ1M Q8T1 顺序写
[SEQ1M-Q8T1-Write]
rw=write
bs=1M
iodepth=8
numjobs=1
stonewall

# group 2. RAND4K Q1T1 随机读
[RND4K-Q1T1]
rw=randread
bs=4k
iodepth=1
numjobs=1
stonewall

# group 3. RAND4K Q1T1 随机写
[RND4K-Q1T1-Write]
rw=randwrite
bs=4k
iodepth=1
numjobs=1
stonewall

git clone https://github.com/Open-CAS/open-cas-linux
cd open-cas-linux
git submodule update --init
./configure
make
sudo make install

sudo casadm -S -i 1 -d /dev/disk/by-id/xxx -c wt

sudo casadm -A -i 1 -d /dev/disk/by-id/xxx

sudo mkdir -p /etc/opencas
sudo nano /etc/opencas/opencas.conf

version=19.3.0
# Version tag has to be first line in this file
#
# Open CAS configuration file - for reference on syntax
# of this file please refer to appropriate documentation

# NOTES:
# 1) It is required to specify cache/core device using links in
# /dev/disk/by-id/, preferably those using device WWN if available:
#   /dev/disk/by-id/wwn-0x123456789abcdef0
# Referencing devices via /dev/sd* is prohibited because
# may result in cache misconfiguration after system reboot
# due to change(s) in drive order. It is allowed to use /dev/cas*-*
# as a device path.

## Caches configuration section
[caches]
## Cache ID     Cache device                            Cache mode      Extra fields (optional)
## Uncomment and edit the below line for cache configuration
1               /dev/disk/by-id/xxx        WT

## Core devices configuration
[cores]
## Cache ID     Core ID         Core device     Extra fields (optional)
## Uncomment and edit the below line for core configuration
1               1               /dev/disk/by-id/xxx

## To specify use of the IO Classification file, place content of the following line in the
## Caches configuration section under Extra fields (optional)
## ioclass_file=/etc/opencas/ioclass-config.csv

## If given cache/core pair is especially slow to start up, often doesn't come back
## up after reboot or you simply don't care if it does and don't want it to have
## an effect on your boot you can mark cores as lazy to prevent Open CAS from
## dropping boot to emergency shell because of this core failure. To do this
## put following line under in Extra fields (optional) section of core config:
## lazy_startup=true
## NOTE: This will cause open-cas.service to not wait for marked core while
## starting up - this option should be used with care to prevent races with
## other services for devices (e.g. mounts based on FS labels)

[Unit]
Description=OpenCAS Cache Setup
DefaultDependencies=no
After=local-fs.target
Before=multi-user.target

[Service]
Type=oneshot
ExecStart=/usr/bin/casctl start
ExecStop=/usr/bin/casctl stop
RemainAfterExit=yes

[Install]
WantedBy=multi-user.target

sudo systemctl daemon-reexec
sudo systemctl daemon-reload
sudo systemctl enable opencas # 开机启动
sudo systemctl start opencas # 启动服务

/dev/cas1-1  /mnt/hdd/seagate  ext4  defaults,x-systemd.automount,nofail  0  2
